Compliant to 400GBASE-LR4

Optical Interface: Compliant to 53.125 GBd PAM4 x 4 wavelength 400G-LR4

Electrical Interface: Compliant to 53.125  GBd PAM4 x 4 lane 400GAUI-8

Integrated CWDM4 EML TOSA / PIN ROSA for up to 10km reach over SMF

Digital Diagnostics Monitoring Interface

 Duplex LC optical interface

Electrically hot-pluggable

Power consumption: 10 W max

Case operating temperature range:0°C to 70°C

● Distance:10km over SMF

● Data Rate:400Gb/s

● Low End Case Temperature (°C):0

● High End Case Temperature (°C):70

● Diagnostics:Digital

● Transmitter:EML TOSA

● Receiver:Pin

● Voltage Supply:3.3V

● Connector: Duplex LC

● Wavelength:CWDM4
