1.25Gb/s downstream / 1.25Gb/s upstream duplex data links that employ high-speed burst mode TDM receivers/transmitters. It is based on the IEEE802.3ah and CTC PX20++ specifications for bidirectional communications over a single fiber and incorporates a high performance 1310nm Burst Mode APD/TIA receiver and 1490nm CW mode DFB transmitter with internal optical isolator. The Transmit Disable (Tx_DIS), Transmit Fault (Tx_FAULT) and the SFF-8472 I2C diagnostic interface monitor and control functions are LVTTL compatible. The industry standard 2x10 small form pluggable (SFP) package incorporates the SC receptacle.Commercial temperature range is available. It is IEC 608251 Class I laser safety compliant and meets the EEC Directive 2002/95/EC for RoHS compliance.
0755-26487154
● Support IEEE802.3ah and CTC PX20++ application
● Single fiber bi-directional data links with symmetric 1.25Gbps Tx and 1.25Gbps Rx
● 1490nm CW(continuous-wavelengh) Mode DFB Laser with Isolator
● 1310nm burst-mode receiver with APD-TIA
● 2-wire interface for integrated digital diagnostic Monitoring
● RSSI function indication (RSSI)
● SFP package with SC/UPC receptacle optical interface
● Single +3.3V power supply
● Operation case temperature: 0~70°C
● Distance:20km
● Data Rate (max):1.25Gb/s
● Low End Case Temperature (°C):0
● High End Case Temperature (°C):70
● Diagnostics:Digital
● Transmitter:DFB
● Receiver:APD
● Voltage Supply:3.3
● Connector:SC
● Wavelength:1490nm/1310nm Band
