Compliant to 400GBASE-DR4

Optical Interface: Compliant to 53.125 GBd PAM4 x 4 wavelength 400G-DR4

Electrical Interface: Compliant to 26.5625 GBd PAM4 x 8 lane 400GAUI-8

Integrated 1310nm DML TOSA / PIN ROSA for up to 500m reach over SMF

Digital Diagnostics Monitoring Interface

MPO-12 optical receptacle

Electrically hot-pluggable

Power consumption: 12 W max

Case operating temperature range:0°C to 70°C

● Distance:500m over SMF

● Data Rate:400Gb/s

● Low End Case Temperature (°C):0

● High End Case Temperature (°C):70

● Diagnostics:Digital

● Transmitter:DML TOSA

● Receiver:Pin

● Voltage Supply:3.3V

● Connector:LC

● Wavelength:1310nm
